VIAIR | Every Vehicle Carry™ 75P Portable Compressor (00075)
SELECT OPTIONS
Description
The Every Vehicle Carry® 75P is a sleek, yet compact portable tire inflator ideal for sedans and hatchbacks. The compressor has a max amp draw of 10A/120W, making it compatible for any compact passenger vehicle on the road. Tire pressure can be monitored using the gauge on the top of the unit. It comes in a steel carrying case with a durable strap.
Specifications
SPECS:
CFM: 1.13 @ 0 PSI
12-Volt
Permanent Magnetic Motor
Duty Cycle: 100% @ 50 PSI
Max. Working Pressure: 50 PSI
Max. Amp/Watt Draw: 10A/120W
Ingress Protection Rating: IP54
Max. Ambient Temp: +158°F
Min. Ambient Temp: -4°F
Dimensions: 9.64″L x 4.33″W x 9.68″H
Net Weight: 4.44 lbs.
Power Cord Length: 10 ft.
Air Hose Length: 2 ft.
FEATURES:
60 PSI Gauge
Vibration Isolators
Press-On Tire Chuck
Integrated Metal Storage Case
Durable Leather Tipped Handle
Accessory Power Plug
3 pc. Inflation Tips Kit
Presta Valve Adaptor
PLEASE NOTE:
Always check your vehicle’s power port rating for maximum amperage before ordering. The 75P does not work with Presta bicycle valves, unless used with a Presta Valve Adaptor(Included). The 75P does not work with the VIAIR Winterization Kit (P/N 90145).
Performance
12-Volt Compressor - Supply Voltage 13.8 Volts
| PSI | CFM | A | BAR | LPM | A |
|---|---|---|---|---|---|
| 0 | 1.13 | 6 | 0 | 32.0 | 6 |
| 10 | 0.96 | 7 | 1.0 | 25.5 | 8 |
| 20 | 0.85 | 8 | 2.0 | 21.0 | 9 |
| 30 | 0.72 | 9 | 3.0 | 17.5 | 9 |
| 40 | 0.64 | 9 | 4.0 | 13.3 | 9 |
| 50 | 0.54 | 9 | 5.0 | 11.0 | 8 |
| 60 | 0.47 | 9 | 6.0 | 9.1 | 8 |
| 70 | 0.41 | 8 | 7.0 | 7.8 | 7 |
| 80 | 0.35 | 8 | |||
| 90 | 0.32 | 8 | |||
| 100 | 0.27 | 7 |
Fill Rates
| 195/70R14 | FILL RATE |
|---|---|
| 27 to 35 PSI | 1 min. 04 sec. (± 05 sec.) |
| 35 to 44 PSI | 1 min. 22 sec. (± 05 sec.) |
| 205/65R16 | FILL RATE |
| 27 to 35 PSI | 1 min. 07 sec. (± 05 sec.) |
| 35 to 44 PSI | 1 min. 29 sec. (± 05 sec.) |
