BLUE SEA SYSTEMS | Water Resistant 100A BusBar (2356)

BLUE SEA SYSTEMS | Water Resistant 100A BusBar (2356)

$37.59
Quantity:

Description

Provides secure water-resistant bussing for harsh environments.

  • Water-resistant design with standard ring or spade type terminals allows for simple wiring with standard tools.
  • Accepts a wide range of wire sizes
  • Includes 3 wire plugs to maintain water-resistant rating if less than 4 wires are used
  • Nests with other Water-Resistant 100A Common BusBars and ST-Blade Water-Resistant Fuse Block for space saving wiring
  • Ideal for positive distribution and for the collection of negative or AC ground circuits
  • 2356100 meets ABYC/USCG insulation requirements
  • Tin-plated copper busses and fuse clips
  • Includes four write-on circuit labels
  • Small format standard and custom labels available

Specifications

Cover Yes
Maximum Voltage 300V AC
48V DC
Terminal Stud 1 x #10-32
Continuous Rating  100A AC
100A DC
Bus Material Tin-Plated Copper C11000
Mounting Holes Accepts 1/4" (6mm) Screws
Terminal Screws 4 x #8-32
Wire Size (1) 8 AWG to 4 AWG - Input
(4) 16 AWG to 10 AWG - Load



(2356)
