BLUE SEA SYSTEMS | Common 100A Mini BusBar 5 Gang (2128)
Quantity:
SELECT OPTIONS
Quantity:
Description
- Great for limited space applications
Specifications
| Maximum Voltage | 300V AC 48V DC |
| Number of Screw Terminals | 5 |
| Number of Terminal Studs | 2 |
| Terminal Type | #10-32 Stud #8-32 Screw |
| Continuous Rating | 100A |
| Base Material | UL 94-V0 Rated, Glass Reinforced Thermoplastics |
| Bus Material | Tin-Plated Copper CDA 110/ UNS11000 |
| Screw Terminal Torque | 15 in-lb (1.69 Nm) |
| Stud Torque | 18 in-lb (2.03 Nm) |
