ARB 4X4 | Air Locker Differential Dana 44 with 35 Splines for Jeep Wrangler JK (Rubicon) (RD157)

ARB RD157 Air Locker Differential Dana 44 with 35 Splines for Jeep Wrangler JK (Rubicon)

Description

Durability

ARB Air Lockers are sold in over 80 countries and there are over 150,000 units currently in use worldwide in both military and civilian applications. The secret to their success and reliability is that each ARB locker is designed and tested beyond the breaking point of standard and aftermarket axles such that your axles will break before causing any damage to the air locker.

Installation

ARB lockers require no special tools or skills to install, apart from those necessary for fitting a standard differential.

Traction

Provides 100% traction on demand without affecting road drivability or driveline wear.Vastly improved traction means less reliance on momentum, thus reducing the likelihood of vehicle damage and environmental impact.

Reliable

Incredibly simple yet effective design that employs minimal moving parts, thereby ensuring maximum reliability.Thoroughly tested and proven design, trusted and used in over 80 countries around the world.

About This Product

With our improved two piece design available right across the range, along with the addition of forged gears and an industry leading five year warranty, ARB Air Lockers are now better built and better backed than ever before. Created to provide 100 percent traction on demand, without sacrificing any of your vehicles highway driving performance, ARB Air Lockers employ a 12 volt ARB Air Compressor designed to activate (and deactivate) a solid and durable locking mechanism inside the differential. This gives you the traction you need, when you need it, all at the flip of a switch and all within the comfort of the drivers seat.

The advantage of the ARB Air Locker lies in the pneumatically operated locking system inside the differential. When activated, the Air Locker prevents the differential gears from rotating and therefore prevents the axle shafts from turning independently of each other. With both wheels tied directly to the rotation of the ring gear, the vehicle maintains maximum possible traction at all times. When unlocked, it operates just like a conventional open differential. In addition to providing outright improvements to a 4x4s off road capabilities, the Air Locker offers significant environmental benefits. An Air Locker equipped vehicle can be driven in a slower, safer and more controlled manner, greatly reducing the likelihood of vehicle damage and environmental impact.

Specifications

Dimensions (L x W x H): 10.63 x 10.63 x 11.02 inches.
Weight: 28.00 lbs.
Differential: Dana 44.
Ratio: All
Axle Splines: 35.
Shaft Diameter: 1.50".
SKU: RD157.
UPC: 881348012241.

Fitment

Jeep, Chrysler

• Wrangler JK Rubicon: 2007 ON
